Description
Product Specs
Application: 1/16 – 1/18 Cars, TrucksBearing: Dual Ball BearingBushing Or Bearing: BearingConnector Type: UniversalCurrent Draw Idle: 150mA @ 4.8V, 180mA @ 6.0V, 240mA @ 7.4V, 300mA @ 8.4VCurrent Draw Stall: 1.6A @ 4.8V, 2A @ 6.0V, 2.2A @ 7.4V, 2.4A @ 8.4VDeadband: 2µsMaximum Servo Speed: 0.09 sec/60 deg @ 6.0V, 0.07 sec/60 deg @ 7.4V, 0.06 sec/60 deg @ 8.4VMaximum Servo Torque: 135oz/in @ 6.0V, 159oz/in @ 7.4V, 179oz/in @ 8.4VProduct Height: 0.47″ (12 mm)Product Length: 1.08″ (27 mm)Product Weight: 0.74oz (21g)Product Width: 0.9″ (23 mm)Programmable: YesServo Operating Voltage: 6.0 – 8.4V (HV)Servo Size Category: MicroServo Type: DigitalSpline Count: 25 – ToothWater-Resistant: Yes
- High Torque High Speed
- Servo / Winch
- Military Grade Construction
- Pulse Width Modulation Control
- SMART Chip Technology
- REEFS LINK required for Programming
- Comes as Servo, Programming required to use as winch
- Voltage 4.8v – 8.4v
- Internal: Metal Gears
- CNC Aluminum Casing
- Sealed Bearing
- Temp Rate: -15 Deg C~ + 70 Deg C
- Operating Travel: 180 Deg +/- 10 Deg
- Mechanical Angle: No Limit
- Motor Drive: IC Drive
- Weight: .24oz / 7g
- Size: 20 x 8 x 17.8 mm (LWH)
- Torque: 37oz @ 6.0v / 43oz @ 7.4v / 49oz @ 8.4v
- Speed: .075 sec @ 6.0v / .058 sec @ 7.4v / .05 sec @ 8.4v
- Spline: 20T 4.0mm
- BEC Not Required, Recommended for Max Performance
