Description
- SizeStandard
- Tubing insertion depth17 mm
- Mounting positionAny
- DesignBlanking plug
- Pack size10
- Structural designPush-pull principle
- Operating pressure for entire temperature range-0.095 MPa … 0.6 MPa
- Operating pressure for entire temperature range-0.95 bar … 6 bar
- Operating pressure for entire temperature range-13.775 psi … 87 psi
- Temperature-dependent operating pressure-0.095 MPa … 1.4 MPa
- Temperature-dependent operating pressure-0.95 bar … 14 bar
- Temperature-dependent operating pressure-13.775 psi … 203 psi
- Information on operating pressureWater: max. 0.6 MPa at max. 50 °C
- Operating mediumCompressed air as per ISO 8573-1:2010 [7:-:-] Water (liquid, ice-free)
- Information on operating and pilot mediaOperation with oil lubrication possible
- Corrosion resistance class (CRC)1 – Low corrosion stress
- LABS (PWIS) conformityVDMA24364-B1/B2-L
- Cleanroom suitability, measured according to ISO 14644-14Class 4 according to ISO 14644-1
- Ambient temperature-10 °C … 80 °C
- Product weight3.5 g
- Pneumatic connection 1For pneumatic tubing outside diameter 6 mm
- Releasing ring colorBlue
- Note on materialsRoHS-compliant
- Housing materialPBT
- Releasing ring materialPOM
- Material of tubing sealNBR
- Material of tube retaining clawHigh-alloy stainless steel
