Description
This is the Hitec HS-5055MG Digital MG Metal-Geared Sub-Micro Servo. Providing 22 oz/in of torque at 6V, this is a great little servo for many projects.Since its introduction, the HS-55 has set the standard for affordable performance, offering precision components that have been engineered to provide long lasting trouble free service!
Enter the new HS-5055MG digital, metal geared version… with this new servo Hitec takes ultra micro performance to the next level without breaking the bank. The new HS-5055MG is a perfect choice for “smaller” high performance electric helicopters, aircraft and sail planes.
Features
- Digital Circuit for Increased Performance and Holding Power
- Smooth Coreless Motor
- Rugged Metal Gears
- Standard Programmable Digital Circuit
- Economical, Feather, Digital Servo
Programmable Functions
End Point Adjustments
Direction
Fail Safe
Dead Band
Speed (Slower)
Data Save / Load
Program Reset
Performance Specifications
Operating Voltage Range (Volts DC)4.8V ~ 6.0V
Speed (Second @ 60°)0.20 ~ 0.17
Maximum Torque Range oz. / in.18 ~ 22
Maximum Torque Range kg. / cm.1.3 ~ 1.6
Current Draw at Idle8 mA
No Load Operating Current Draw120 mA
Stall Current Draw700 mA
Dead Band Width6 µs
Physical Specifications
Dimensions (Inches)0.89 x 0.45 x 0.94
Dimensions (Metric)22.8 x 11.6 x 24.0
Weight (Ounces)0.33
Weight (Gram)9.5
Circuit TypeG1 Programable Digital
Motor Type3 Pole Metal Brush Ferrite
Gear MaterialMetal
Bearing TypeNone
Connector Gauge (AWG) / Strand Count28 / 20
