Dynam Sbach 342 1250mm 4S RC Aerobatic 3D Sport Plane 2.4Ghz 49inch Wingspan – PNP/BNF/RTF-8C -DY8945
The Dynam RC Sbach 342 is a high-performance aerobatic 3D airplane designed for intermediate to advanced pilots. It features a sleek and streamlined design with a wingspan of 1250mm and a fuselage length of 1235mm. A lightweight EPO foam construction for durability and maneuverability. The Sbach 342 RTF version comes with a powerful Detrum BM3720A-KV650 brushless motor, a TomCat Skylord-50A ESC, four servos, a 4S 14.8V 2200mAh 25C LiPo battery, and a GAVIN 8-channel radio system, providing precise control and speed. The Dynam Sbach 342 can perform various aerobatic maneuvers, including rolls, loops, spins, and inverted flight.
Specs
Wingspan: 1250mm (49in)
Overall Length: 1235mm (48.6in)
Flying Weight: 1450g (51.14oz)
Wing Loading: 46.5g/dm²
CG (Center of Gravity): 75-80mm from the leading edge of the wing at the root
Power System: Detrum BM3720-KV650 Brushless Outrunner motor – (pre-installed)
Electronic Speed Control: TomCat Skylord-50A 5A-BEC ESC – (pre-installed)
Propeller: 13*6 2-Blade Prop
Servo: 4x 9g micro servos – (pre-installed)
Landing Gear: Fixed
Required Transmitter: GAVIN-6C 2.4Ghz 6-Channel or above
Required Receiver: MSR66A 6CH 2.4Ghz (iStone 6-Axis Gyro Stabilizer w/ ABS System)
Required Battery: 4S 14.8V 2200mAh 25C Li-Po w/ XT60 Connector
Aileron: Yes
Elevator: Yes
Rudder: Yes
Flaps: No
Approx. Flying Time: 7 minutes
Material: EPO Foam
Skill Level: Intermediate
Assembly Time: 1 hour
Age Level: 14+
Recommended Environment: Outdoor
Aircraft Type: Aerobatic
Key Features
Durable and lightweight EPO construction.
Realistic scale features include an attractive Sbach 342 paint scheme, a hand-painted pilot figure, and molded panel lines.
A composite structure low-wing monoplane with a fixed conventional landing gear with a tailwheel.
Elevator, aileron, and elevator controls.
Comes with a decal set.
Suitable for intermediate or experienced pilots.
Version For Your Reference:
1) SRTF (Inc. GAVIN-8C TX (Mode 1)+RX with 6-Axis Gyro) INCLUDES:
-
Dynam Sbach 342 1250mm (49″) Wingspan – (RTF)
-
Servo: 9g*4pcs
-
Battery: 14.8V 2200mAh 25C Lipo battery
-
ESC: 50A ESC with 5A BEC with XT60 connector
-
Brushless motor: BM3720A-KV650 Outrunner
-
Charger: Supermate 4 blanace charger+2A adaptor
-
Radio: GAVIN-8C 8CH 2.4G TX (Mode 1) (Click here to check)
-
Receiver: Detrum MSR66A 6-Channel 2.4Ghz Mini Receiver with iStone 6-Axis Gyro/ABS (Click here to check)
-
Decal set
REQUIRES:
- Nothing! Everything you need to fly is included in the box.
2) SRTF (Inc. GAVIN-8C TX (Mode 2)+RX with 6-Axis Gyro) INCLUDES:
- Dynam Sbach 342 1250mm (49″) Wingspan – (RTF)
-
Servo: 9g*4pcs
-
Battery: 14.8V 2200mAh 25C Lipo battery
-
ESC: 50A ESC with 5A BEC with XT60 connector
-
Brushless motor: BM3720A-KV650 Outrunner
-
Charger: Supermate 4 blanace charger+2A adaptor
-
Radio: GAVIN-8C 8CH 2.4G TX (Mode 2) (Click here to check)
-
Receiver: Detrum MSR66A 6-Channel 2.4Ghz Mini Receiver with iStone 6-Axis Gyro/ABS (Click here to check)
-
Decal set
REQUIRES:
- Nothing! Everything you need to fly is included in the box.
3) BNP (PNP+2.4G receiver with 6-Axis Gyro w/ABS)
- Dynam Sbach 342 1250mm (49″) Wingspan – (PNP)
-
Servo: 9g*4pcs
-
ESC: 50A ESC with 5A BEC with XT60 connector
-
Brushless motor: BM3720A-KV650 Outrunner
-
Receiver: Detrum MSR66A 6-Channel 2.4Ghz Mini Receiver with iStone 6-Axis Gyro/ABS (Click here to check)
-
Decal set
REQUIRED:
-
Battery: 14.8V 2200mAh 25C Lipo battery,
-
Charger: 4S Charger
-
Required Radio: 6+ Channel 2.4Ghz, Click here check in our radio catelogo
4) PNP
- Dynam Sbach 342 1250mm (49″) Wingspan – (PNP)
-
Servo: 9g*4pcs
-
ESC: 50A ESC with 5A BEC with XT60 connector
-
Brushless motor: BM3720A-KV650 Outrunner
-
Decal set
REQUIRED:
-
Battery: 14.8V 2200mAh 25C Lipo battery,
-
Charger: 4S Charger
-
Required Radio set: 6+ Channel 2.4Ghz , Click here check in our radio catelogo
