Description
Specifications:
- Motor shaft diameter: 5mm
- Motor shaft length: 21mm
- Stator Diameter: 32mm
- Stator Thickness: 20mm
- No. of Stator Arms: 8mm
- Number of slots/poles: 10N/10P
- Motor Wind5+3 Turn Delta
- Motor wire diameter: 0.86mm
- Motor Kv: 960KV RPM/Volt
- No-Load Current: (10/10v) Amps
- Max Continuous Current: 85 Amp
- Max Continuous Power: 1750 Watt
- Weight: 172 Grams
- Outside Diameter: 40.8 mm
- Shaft Diameter: 5 mm
- Body Length: 54.5 mm
- Overall Shaft Length: 90 mm
- Max Lipo Cell: 6s
- Peak Continuous Current: 105 Amps (5seconds)
- Peak Continuous Power: 2260 Watts (5 seconds)
- Motor Timing: 5deg~12deg
- Drive Frequency: 8kHz~32khz
