Description
40-Amp Lite Pro Switch-Mode BEC Brushless ESC
Key Features:
• Up to 40-amp continuous current with proper airflow, 55-amp burst current
• 5-volt Switch-Mode BEC circuit capable of 2.5-amp continuous current
• Drives up to 7 analog or 6 digital standard-sized servos with the BEC on any recommended input voltage
• 3S-6S LiPo or 9- to 18-cell Ni-MH/Ni-Cd input voltage
• Programmable motor braking
• Safe power-arm mode prevents accidental starts
• Programmable soft start for helis and airplanes
• Auto motor shutdown if signal is lost or there is interference
• Programmable timing – 5 user-selectable ranges for use with a larger variety of brushless motors
• Programmable throttle input range (1.1–1.9ms or 1.2–1.8ms)
• Heli mode for starting the motor with a low speed ratio
• Optional RS232 Serial Link available for programming (EFLARS232)
• Pre-wired connectors-E-flite EC3 connectors on battery input and 3.5mm female gold bullets on motor output leads
Overview:
For up to 40 amps of continuous current with proper airflow, the E-flite 40-Amp Lite Pro SB brushless ESC delivers. It drives up to 7 analog or 6 digital servos with the BEC on any recommended input voltage. This brushless ESC includes programmable motor braking, soft start for helis and planes, timing, throttle input range and low voltage cutoff.
It also features auto motor shutdown in case of lost signal or interference. The safe power-arm mode prevents accidental starts. All the great features of E-flite’s popular 40-Amp Pro SB Brushless ESC, in a lighter weight package perfect for use in large-size park flyers and mid-size models where space and weight are more critical.
